DVI2PCIe Internal DVI, VGA, HDMI Capture Card

DVI2PCIe is an internal video capture card from Epiphan Video. DVI2PCIe can capture video from any dual-link or single-link DVI, unencrypted HDMI video, VGA, or BNC/component video source up to 80 FPS. Full HD can be captured at a capture rate of 60 frames per second for full 1080p video and video sources at any resolution up to 2048×2048 are supported.

Key Features:

– Lossless Capture from DVI, VGA, HDMI, RGB, component sources
– Support for DisplayPort, Mini DisplayPort, and Thunderbolt sources using a converter cable, sold separately
– PCIe x4 form factor. Compatible with PCI Express x4, x8, and x16 slots
– Full HD 1080p capture at 60 FPS or better
– Capture rates of 60 to 80 frames per second based on resolution selected
– Epiphan Capture Tool software included for capturing and recording video
– Easy to install and configure, software automatically optimizes settings
– Supports Windows, Mac OS, and Linux
– DirectShow (Windows), QuickTime (Mac OS), and Video4Linux (Linux) drivers available
– Supports 3rd party applications that accept an external video source, such as Windows Media Encoder, Adobe Premiere, Podcast Producer, and others
– Free API and SDK available for integrating into custom applications

What’s in the box? DVI2PCIe comes with:

• DVI2PCIe board (with full-height case bracket installed)
• a DVI cable (male to male)
• a DVI to VGA cable (male to male)
• an HDMI to DVI adapter (female to male)
• a low profile bracket for half-height cases

Captures from single-link and dual-link DVI, HDMI, VGA, RGB and component sources
Support for DisplayPort, Mini DisplayPort, and Thunderbolt sources using a converter cable, sold separately
PCIe x4 form factor. Compatible with PCI Express x4, x8, and x16 slots
Full HD 1080p capture at 60 fps
Supports unusual and custom VGA modes and resolutions
